200000303 Waters ACQUITY M-Class UPLC with HDX Technology Kit
ENVIRONMENT
- nanoACQUITY UPLC
- ACQUITY UPLC M-Class
CONTENT
Waters nanoACQUITY UPLC with HDX Technology Kit, Part Number 200000303
| Part Number | Quantity | Item | Image | Description/Location |
|---|---|---|---|---|
|
|
2 |
Union, 1/16”, 10-32 |
 |
Replaces digestion column when not in use, injection. |
|
|
5 |
1/16” Peek Ferrules |
 |
Replacement ferrules used in the injector assembly. |
|
|
3 |
Tubing, Peek, 0.062” OD x .005” ID x 5’ lg |
 |
Low pressure connections in HDX. |
|
|
3 |
Tubing, Peek, 0.062” OD x .010” ID x 5’ lg |
 |
Waste lines from HDX. |
|
|
48” |
Tubing, 1/4” OD x 1/8” ID, Pharmed |
 |
Shroud tubing for capillary line from HDX to MS. |
|
289006305 |
1 |
Column Holder Assembly |
 |
Holds analytical column in place. |
|
289006699 |
1 |
Assy, Valve Pod Holder |
 |
Holds valve pods when removed, allows for easy plumbing. |
|
|
2 |
Conn Plug, 10-Pin |
 |
Event terminals on EM. |
|
|
1 |
Microfilter, precolumn, 2um, ss, 1/16” |
 |
Pre-injection Valve (Port #2) or injection union. |
|
|
2 |
Peek 1/16” OD x .0025” ID x 5’ lg |
 |
Column to MS line, 1 extra included. |
|
|
2 |
Tubing, Sleeve, .062” x .015” |
 |
Outlet line strain relief at HDX fluid block. |
|
|
60” |
Tubing, .375” OD x .250” ID, Tygon 2075 |
 |
Waste outlet tubing. |
|
430001325 |
1 |
50 µl Loop |
 |
Sample loop for 1.0 mm scale separations. |
|
|
4 |
Tubing, Capillary w/frit, 75µm x 10” |
 |
H.P. Plumbing inside the chiller module, 3 extra lines included. |
|
5 |
Tube, Inj Port, .062” OD X .030” ID X 1.50” lg |
 |
Replacement lines used in the injector assembly. |
|
|
430003164 |
1 |
Diffuser Tubing Assembly |
 |
Thread into fitting inside the chiller module. |
|
|
1 |
Event Cable Assembly, 6’ lg |
 |
Triggering mass spectrometer after injection. |
|
605000141 |
1 |
M2 Hex Driver |
 |
Valve pod removal. |
|
700002524 |
2 |
Peek Fingertight One-Piece Fitting, 10 Pkg |
 |
Plumbing peek lines. |
