205000355 Waters ACQUITY UPLC Multiple Detector Drip Tray Kit
ENVIRONMENT
- ACQUITY UPLC Tunable UV Detector
- ACQUITY UPLC PDA Detector
- ACQUITY UPLC PDA eλ Detector
- ACQUITY UPLC FLR Detector
- ACQUITY UPLC ELS Detector
- ACQUITY QDa Mass Detector
CONTENT
Waters ACQUITY UPLC Multiple Detector Drip Tray Kit, Part Number 205000355
| Part Number | Quantity | Item | Image | Description/Location |
|---|---|---|---|---|
|
415000715 |
1 |
TRAY, WASTE DRAIN |
 |
Detector Drip Tray for leak management |
|
410001320 |
1 |
FITTING, 1/4 BARB X 18-27 NPT MALE ELBOW |
 |
Fitting for leak management |
|
405003428 |
4 |
PAD, ANTI-SKID, FOOT |
 |
Pads to use on bottom of WAT078180 for stability |
|
WAT025249 |
6 |
RIVET, SNAP, .256 MAX PANEL |
 |
Rivets to hold drip tray in place |
|
|
4 |
BUMPER,RUBBER,.62DIA.X.75 |
 |
Rubber feet to increase the high of the detector |
|
WAT411430 |
4 |
SCREW, M4 X 30, PAN HEAD, HEXALOBULAR, S |
 |
Screws to hold rubber feet in place |
|
|
1 |
FITTING, BARBED, ELBOW, 1/4 ID |
 |
Fitting for leak management |
|
|
10" |
TUBING, .375 OD X .250 ID, TYGON |
 |
Waste Tubing |
|
|
1 |
ELBOW, DRAIN, 1/8 NPT TO BARBED |
 |
Fitting for leak management |
|
|
1 |
Y-CONNECTOR, BARBED, 1/4" ID TUBE |
 |
Fitting for leak management |
ADDITIONAL INFORMATION
How to Install the ACQUITY Multi-Detector Drip Tray - wkb62036
