200000204 Waters e2695 Separations Module Startup Kit
ENVIRONMENT
- Alliance HPLC System
- 2695 Separations Module
CONTENT
Waters e2695 Separations Module Startup Kit, Part Number 200000204
| Part Number | Quantity | Item | Image | Description/Location |
|---|---|---|---|---|
|
WAT027033 |
6 |
Cable tie miniature |
![]() |
Used to dress the cable and tubings during system installation. |
|
|
1 |
Stoppers, 4L Bottle (4/pkg) |
Bottle Caps for Reservoir Management. |
|
|
WAT251468 |
3 |
Clip, Cable, Snap-In |
|
Mount on Back Panel for Tubing Management. |
|
WAT270389 |
2 |
Clip, Column Mount, External |
Column Clips for Outside Syringe Compartment. |
|
|
|
1 |
Adapter, Seal Wash to Syringe |
![]() |
Priming Seal Wash Lines. |
|
|
1 |
Syringe, Plastic, 30mL |
|
System Priming. |
|
|
1 |
Vials, 2 mL (100/pkg) |
![]() |
Glass Screw Neck Vial with Quick Thread design Cap with LectraBond Cap and Bonded PTFE/pre-Slit Silicone Septa. |
|
410000760 |
2 |
Fitting, One-Piece 10-32 Finger Tight |
|
Tubing Connections for both PEEK and Stainless Steel Tubing. |
|
410000767 |
4 |
Retainer |
|
Holds Down Larger Dia. Drain Tube. |
|
410000771 |
4 |
Clip Cable Routing ¼ dia. |
|
Holds Drain Tubing Down. |
|
|
2 |
Fitting, Barbed, Elbow ¼ID |
|
Drain Lines Bends at Bench Top for Larger Dia. Drain tube. |
|
430000763 |
120 in |
Tubing, Polyethylene ¼” |
![]() |
Larger Dia. Drain tubing. |
|
|
1 |
Assy., Tube, PEEK, .005ID, 20.0” Long |
Column Connections. |
|
|
430001910 |
1 |
Tubing, Set, .062OD x .009ID x 20.0” Long |
|
Used for Column Connections. |
|
|
1 |
Ethernet Patch Cord, Shielded, 10' L |
![]() |
Cable used to connect Ethernet Detectors. |
|
|
2 |
Lower Seal Wash Frit, 5 pkg. |
|
Replacement Frit for Seal Wash. |
